Industrial wireless data transmission terminal is a 4G/NB-IoT wireless data transmission terminal equipment based on the full netcom network of China Mobile, China Unicom and China Telecom. It provides the wireless data transmission channel of TCP/IP network protocol for industrial users, and can provide a fully transparent data channel to achieve two-way data transparent transmission from serial port to network. Realize wireless data communication between the field RS485/RS232/RS422 bus equipment and the central control system. Product communication stability, easy to use, industrial protection ability is superior, especially suitable for harsh industrial environment.
1. Support RS232/485/422 to 4G
2. Support full Netcom 4G, 4 modes and 14 bands, cost-effective
3. Support AT command control, support heartbeat packet, registration report function
4. Support network transparent transmission + MQTT + Modbus and other working modes
5. Industrial-grade design, stable and reliable
| Hardware parameters | |
| Product model | VS351 |
| Network standard | China Mobile, China Unicom, China Telecom 4G, LTE FDD: B1/B3/B5/B8 LTE TDD: B34/B38/B39/B40/B41 WCDMA: B1/B5/B8 GSM: 900/1800MHz |
| Serial - Number of ports | 1 x RS-232/RS-485/RS-422 |
| Serial-interface form | RS-232 interface: DB9 pin male RS-485/RS-422 interface: 5-digit 3.81mm pitch industrial grade terminal block |
| Serial port - communication rate | 600~460800bps |
| Serial port - data format | Support data bits: 8 bits, stop bits: 1~2 bits, check bits: no check/ODD odd check/EVEN even check |
| Electricity | External DC: DC9~36V, support anti-reverse polarity protection function |
| Consumption | 56mA（@12VDC） |
| ESD indicators | EN61000-4-2 ESD Level 4: ±8kV contact discharge, ±15kV air discharge |
| Ingress protection | Surge Protection: Power : ±2kV/common mode, ± 2kV/differential mode Data port: ±2kV/common mode, ±2kV/differential mode EFT Test: Power supply: ±2kV, data port: ±2kV |
| Product Certification | CE、FCC、RoHS |
| Exterior dimensions | 96mmX90mmX26mm |
| Operating temperature | -40℃～+85℃ |
| Storage temperature | -40°C~+85°C 5%~95% RH (no condensation) |
| Software parameters | |
| Network protocols | IPv4、TCP、UDP |
| Configuration | AT Command |
| Simple transparent transmission method | TCPClient/UDP Client/SSL |
| Modbus | Modbus RTU/TCP |
| Serial port data packaging mechanism | The default packaging time is 500ms, and the packaging length is 1000bytes |
| MQTT | Alibaba MQTT/China Mobile OneNet MQTT |
| Network caching | Send: 1Kbyte Receive: 1Kbyte |
| Serial port cache | Send: 1Kbyte Receive: 1Kbyte |
| The number of socket connections that are supported | 2-way, independent of each other |
| Supporting software | DTU configuration tool |
